BAUER PE250/420-VE
Charging rate - 250 lit/min
Operating pressure - 420 bar
Purification system - P41/420
Motor - 3-phase, power 5.5 kW, 400V, 50Hz
Weight - 292 kg
Dimensions - 114 x 83 x 152 cm
Stationary model of open type
Compressor control B-control micro
Automatic irradiation
Condensate tank 10 lit
Monitoring of maximum pressure, oil pressure, last stage temperature, air cooling temperature
No filling hose
Additional options:
- Super silent
- safety valve with TUV setting
- external suction "over roof" (can cause a decrease in filling speed)
- B-app ready (B-link)
- condensate tank 60 lit
- B-Securus monitoring
- B-cool
- extended chassis base
- 4 outlets for filling at 200 or 300 bar (connection with hoses or direct)
- switch 200/300 bar with 2x200/2x300 bar (connection with hoses or direct)
BAUER PE320-VE
Charging rate - 320 lit/min
Operating pressure - 420 bar
Purification system - P41/420
Motor - 3-phase, power 7,5 kW, 16A, 400V, 50Hz
Weight - 299 kg
Dimensions - 114 x 83 x 152 cm
Stationary model of open type
Compressor control B-control micro
Automatic irradiation
Condensate tank 10 lit
Monitoring of maximum pressure, oil pressure, last stage temperature, air cooling temperature
No filling hose
Additional options:
- Super silent
- safety valve with TUV setting
- external suction "over roof" (can cause a decrease in filling speed)
- B-app ready (B-link)
- condensate tank 60 lit
- B-Securus tracking
- B-cool
- extended chassis base
- 4 outlets for filling at 200 or 300 bar (connection with hoses or direct)
- switch 200/300 bar with 2x200/2x300 bar (connection with hoses or direct)
BAUER PE500-VE
Charging rate - 500 lit/min
Operating pressure - 420 bar
Purification system - P41/420
Motor - 3-phase, power 11 kW, 16A, 400V, 50Hz
Weight - 304 kg
Dimensions - 114 x 83 x 152 cm
Stationary model of open type
Compressor control B-control micro
Automatic irradiation
Condensate tank 10 lit
Monitoring of maximum pressure, oil pressure, last stage temperature, air cooling temperature
No filling hose
Additional options:
- Super silent
- safety valve with TUV setting
- external suction "over roof" (can cause a decrease in filling speed)
- B-app ready (B-link)
- condensate tank 60 lit
- B-Securus monitoring
- B-cool
- extended chassis base
- 4 outlets for filling at 200 or 300 bar (connection with hoses or direct)
- switch 200/300 bar with 2x200/2x300 bar (connection with hoses or direct)
BAUER PE600-VE
Charging rate - 560 lit/min
Operating pressure - 420 bar
Purification system - P61/420
Motor - 3-phase, power 15 kW, 32A, 400V, 50Hz
Weight - 378 kg
Dimensions - 114 x 83 x 152 cm
Stationary model of open type
Compressor control B-control micro
Automatic irradiation
Condensate tank 10 lit
Monitoring of maximum pressure, oil pressure, last stage temperature, air cooling temperature
No filling hose
Additional options:
- Super silent
- safety valve with TUV setting
- external suction "over roof" (can cause a decrease in filling speed)
- B-app ready (B-link)
- condensate tank 60 lit
- B-Securus monitoring
- B-cool
- extended chassis base
- 4 outlets for filling at 200 or 300 bar (connection with hoses or direct)
- switch 200/300 bar with 2x200/2x300 bar (connection with hoses or direct)
